Tuesday, 24 September 2019

SCCM application Dependency and Supersedence








How do we get an SCCM application's dependency and supersedence details using Powershell?

When we need to retire an SCCM application from console we need to see the application's dependency and supersedence information, getting this information is little difficult through Powershell as there is no direct property available to call the details on get-cmapplication cmdlet. Instead, there is a property called "SDMPackageXML" where all these information's are available. Since the information is in XML format we need to deserialize the XML to read the information properly.
Please follow the below steps to get the SCCM application dependency and supersedence information through PowerShell

Application dependency

Below is the property of an application in SCCM (Adobe Reader DC 11)















Once we select the application, then go to deployment tab property to get the application dependency as shown below. As per the below example, "Acrobat Reader DC 10" is the dependent application




















Below is the PowerShell cmdlet to get the application details.

Get-CMApplication "Adobe Reader 11.0.0.0"

Please note the "SDMPackageXML" property from the below result.




















Now we need to deserialize the XML format to read the information easily.
Serializes or deserializes an application between the C# instance and the XML format, see the below link for more information.
https://docs.microsoft.com/en-us/previous-versions/system-center/developer/jj154378(v%3Dcmsdk.12)
$XMLDeS = [Microsoft.configurationmanagement.applicationmanagement.serialization.sccmserializer]::DeserializeFromString($Application.SDMPackageXML,$true)
$XMLDeS.DeploymentTypes
From the below result, we can see application dependency and supersedence information.

The information which is required for us is inside the "Operands " property. Go to operands property using the below cmdlet.

$XMLDeS.DeploymentTypes.dependencies.Expression.Operands

















From the above information, we can see the dependent application information, but the problem is Instead of application name we got the application scope ID and Application logical name. Now the question is how do we get the application information using scope ID and Logical Name? It is easy as we can see the application scope ID and logical name is visible in get-cmapplication property.
From the below example we can see both information is available in "Model" property in a combined format using a forward slash (/)
Get-CMApplication "Adobe Reader 11.0.0.0"


Now we need to join the application scope ID and logical name to search the application using the model name, follow the below cmdlet


$GetModel = $XMLDeS.DeploymentTypes.dependencies.Expression.Operands
$ModelName = $GetModel.DeploymentTypeAuthoringScopeId + '/' + $GetModel.ApplicationLogicalName
$ModelName









As per the above example, we got the application model name, now we need to seach the application using get-cmapplication cmdlet as showing below


Get-CMApplication | Where-Object {$_.ModelName -eq "$ModelName"}

now we will get the dependency application name

Application Supersedence.

Below is the application supersedence option of an application (Right-click on the application)













we need to follow the same steps here to deserialize the XML format

$XMLDeS = [Microsoft.configurationmanagement.applicationmanagement.serialization.sccmserializer]::DeserializeFromString($Application.SDMPackageXML,$true)
$XMLDeS.DeploymentTypes

From the below result, we can see application supersedence information.
















We need to select the supersedence option to see more details as shown below.

$XMLDeS.DeploymentTypes.supersedence


















We need to filter the expression property to identify the superseded applications name as shown below.

$XMLDeS.DeploymentTypes.supersedence.expression.















Now we need to follow the same process used to get the dependency application name here.

Since we are expecting multiple supersedence for the same application, we need to pass the application through a foreach loop as shown below to fetch all the superseded application list






















We got the two supersedence application details with a semicolon-separated value.

Tuesday, 5 March 2019

Powershell Web Access


Sometimes we used to monitor some websites continually for getting a specific information, like breaking news, online product availability checks etc: Here I am showing how can we capture a website information suing powershell. From the below example I am capturing information from one of the online newspaper and displaying as a popup notification, I used windows form to create the popup notification. Please follow the below script to capture some information from a website and display as a popup notification on your desktop.
There are three faces in this script,
  1. Capture the information from a website.
  2. Create a windows form to display the output.
  3. Schedule a task to run the script in a specific time\date.

We are using Invoke-WebRequest PowerShell cmdlet to capture the information from the website, please go through the below Microsoft website to know more about the cmdlet


Before we start we need to have some basic understanding about HTML to identify what is an HTML “Class” and “tags” (Div, H2, UL Etc.), then decide what information we are going to capture from the website and access the DevTool (Developer Console) from the website. Below are some examples to capture the information from the website

Browse the website by typing the URL


Right click on the page (The area which we are going to capture) and click on Inspect (I am using Chrome, it’s Inspect element in IE) to access the DevTool, we can easily identify the required HTML tag and class from DevTool.








































As per the above example, we are going to display the news headlines which is arranged using an HTML List tag (UL Tag) and its class name is list8 – Based on the website design change, the HTML class name and tag may get changed.

Let’s start Part -1 Getting Information from the website

We are going to load the newspaper page on a PowerShell console, before loading the website I have declared some variable for getting the basic details about the website name, URL, html tag and class name


$WebsiteURL = "https://timesofindia.indiatimes.com/"
$WebsiteName = "Time of India"
$Class = "list8"

$TypeClass = "ul"

I am saving the website page in a variable, please check the below screenshot to know more about the properties of the web request stored in the variable. The variable contains a huge amount of details about the website

$WebRequest = Invoke-WebRequest $WebsiteURL

$News = ($WebRequest.ParsedHtml.getElementsByTagName("$TypeClass"| Where$_.className -eq "$Class" } ) | Select-Object -ExpandProperty innertext -First 1

































ParsedHtml – It is basically taking in HTML code and extracting relevant information like the title of the page, paragraphs in the page, headings in the page, links, bold text etc.

GetElementsByTagName – The getElementsByTagName() method returns a collection of all elements in the document with the specified tag name, as a NodeList object.

Part 2 - Creating a Windows form to display the news


Follow my below post about “How to build a form in PowerShell?” to understand more about the windows form.



We have captured the required information from the website and stored in a variable called $News, we need to now display the information on a window, please follow the below cmdlet to create a windows form to hold the information

Basic Form creation cmdlet, I did some customization in our form.

$Form = New-Object system.Windows.Forms.Form
$Form.Size = New-Object System.Drawing.Size(800,400)
$Form.AutoSize = $false
$Form.AutoSizeMode = "GrowAndShrink"
$Form.Text = "News Update"
$Form.StartPosition = "CenterScreen"
$Form.FormBorderStyle = 'Fixed3D'
$Form.KeyPreview = $True
$Form.MaximizeBox = $false

Below is the output display part of the form, you can customize based on your requirement.

$Font = New-Object System.Drawing.Font("Segoe UI",15,[System.Drawing.FontStyle]::Italic)
$outputBox = New-Object System.Windows.Forms.TextBox
$outputBox.Location = New-Object System.Drawing.Size(10,10)
$outputBox.Size = New-Object System.Drawing.Size(780,330)
$outputBox.Font = $Font
$outputBox.MultiLine = $True
$outputBox.ScrollBars = "Vertical"
$outputBox.BackColor = "skyblue"
$OutputBox.AppendText("LATEST NEWS FROM TIMES OF INDIA`n")
$OutputBox.AppendText("$news`n")
$Date = get-date
$OutputBox.AppendText("Updated : $Date")
$OutputBox.Refresh()
$OutputBox.ScrollToCaret()

Below is the hyperlink creation in form in the bottom of the window to navigate to the website to read more information

$LinkLabel = New-Object System.Windows.Forms.LinkLabel
$LinkLabel.Location = New-Object System.Drawing.Size(10,345)
$LinkLabel.Size = New-Object System.Drawing.Size(100,50)
$LinkLabel.LinkColor = "BLUE"
$LinkLabel.ActiveLinkColor = "RED"
$LinkLabel.Text = "$Websitename"
$LinkLabel.add_Click({[system.Diagnostics.Process]::start("$WebsiteURL")})

Now add all the controls to form and display the output

$Form.Controls.Add($outputBox)
$Form.Controls.Add($LinkLabel)
$Form.ShowDialog()

Finally, below is the output

























Part-3 Schedule a task to run the script in a specific time\date.

Now we can run the below PowerShell command for scheduling our news update. Please note that the task scheduler command works only on the latest Powershell version, if you are using old PowerShell version, please import the module frPowerShellell gallery.

$Trigger= New-ScheduledTaskTrigger -At 10:00am –Daily
$UserDetails = "administrator"
$Action= New-ScheduledTaskAction -Execute "PowerShell.exe" -Argument "D:\Powershell Script\NewsScript.ps1"
Register-ScheduledTask -TaskName "NewsUpdate" -Trigger $Trigger -User $User -Action $Action -RunLevel Highest –Force

Bellow is the another example of collecting HTML details from an online shopping website, we can create a script to get notifications for product availability - Please try to create the script.
